High voltage systemLFP Battery Module 76.8V50Ah(3.84kWh Series capacity increase)

		ASW08kH-T1	ASW10kH-T1	ASW12kH-T1
PV Input	Max. PV array power	12 kWp STC	15 kWp STC	18 kWp STC
	Max. input voltage	1000 V
	MPP voltage range	180 V to 850 V
	Min. input voltage / start voltage	125 V / 180 V
	No. of independent MPPT trackers / strings per MPPT input	2 / (1/1)
	Max. input current per MPP tracker	13 A
	Max. short-circuit current per MPP tracker	25 A
Battery	Battery type	Lithium-ion
	Battery voltage range	150 V to 600 V
	Max. charging / discharging power	8.8 kW / 8.8 kW	11 kW / 11 kW	13.2 kW / 13.2 kW
	Max. charging current / discharging current	50 A / 50 A
	Rated. charging current / discharging current	40 A /40 A
	Compatible Battery	ZEN EcoPrime-series
AC output	Nominal AC voltage	3W+N+PE, 220 V / 380 V; 230 V / 400 V; 240 V / 415 V
	AC voltage range	360 V – 440 V
	Rated AC grid frequency	50 Hz / 60 Hz
	AC grid frequency range	50 Hz±5Hz / 60 Hz±5Hz
	Rated active power	8 kW	10 kW	12 kW
	Rated apparent power	8 kVA	10 kVA	12 kVA
	Max. apparent power	8.8 kVA	11 kVA	13.2 kVA
	Rated grid output Current (@400V)	11.6 A	14.5 A	17.4 A
	Max. grid output current	12.7A	15.9A	19.1A
	Harmonics THDi (@ Nominal power)	< 3%
AC input	Rated grid voltage	3W+N+PE, 220 / 380 V; 230 / 400 V; 240 / 415 V
	Rated grid frequency	50 Hz / 60 Hz
	Rated apparent power	16 kW	20kW	24 kW
	Max. input apparent power from grid	17.6 kVA	22 kVA	26.4 kVA
	Rated input current from grid	23.1 A	28.9 A	34.7 A
	Max. input current from grid	25.5 A	31.8 A	38.2 A
EPS output	Nominal output voltage	3W+N+PE, 220 / 380 V; 230 / 400 V; 240 / 415 V
	Nominal output frequency	50 Hz / 60 Hz
	Rated apparent power	8 kVA	10 kVA	12 kVA
	Max. output apparent power	8 kVA	10 kVA	12 kVA
	Peak output apparent power	8.8 kVA	11 kVA	13.2 kVA
	Rated Current (@400V)	11.6 A	14.5 A	17.4 A
	Max. output current	12.7 A	15.9 A	19.1 A
	Max. switch time	≤ 20 ms
	Output THDi (@ Linear load)	< 2%
