Low Voltage System LFP Battery Module 51.2V 105Ah

		ASW3000H-S2	ASW3680H-S2	ASW4000H-S2	ASW5000H-S2	ASW6000H-S2
PV Input	Max. PV array power	5500 Wp STC	6180 Wp STC	6500 Wp STC	7500 Wp STC	9000 Wp STC
	Max. input voltage	550 V
	MPP voltage range / rated input voltage	40 V to 530 V / 380 V
	Min. input voltage / start voltage	40 V / 50 V
	No. of independent MPPT trackers / strings per MPPT input	2 / 1
	Max. input current per MPP tracker	16 A
	Max. short-circuit current per MPP tracker	20 A
Battery input	Nominal battery voltage	48 V
	Battery voltage range	40 V to 60 V
	Max. charging / dischargingpower	5000 W / 5000 W
	Max. charging current / Max. discharging current	100 A / 100 A
	Battery type	Li-Ion
	Battery type	ZEN Eco-series
AC output	AC voltage range / Nominal AC voltage	180 V to 280 V / 230 V
	Rated AC grid frequency	50 Hz / 60 Hz
	AC grid frequency range	50 Hz±5Hz / 60 Hz±5Hz
	Rated active power	3000 W	3680 W	4000 W	5000 W*¹	6000 W
	Rated apparent power	3000 VA	3680 VA	4000 VA	5000 VA*¹	6000 VA
	Max. apparent power	3000 VA	3680 VA	4000 VA	5000 VA*¹	6000 VA
	Rated grid output Current (@230V)	13.1 A	16 A	17.4 A	21.7 A*²	26.1 A
	Max. grid output current	13.6 A	16 A	18.2 A	22.7 A*²	27.3 A
	Harmonics THDi (@ Nominal power)	< 3%
AC input	Rated grid voltage	a.c. 230V
	Rated grid frequency	50Hz / 60Hz
	Rated apparent power	6000 VA
	Max. input apparent power from grid	6000 VA
	Rated input current from grid	a.c. 26.1 A
	Max. input current from grid	a.c. 27.3 A
EPS output	Nominal output voltage	230 V
	Nominal output frequency	50 Hz / 60 Hz


		ASW3000H-S2	ASW3680H-S2	ASW4000H-S2	ASW5000H-S2	ASW6000H-S2
EPS output	Rated apparent power	5000 VA
	Max. output apparent power	5000 VA
	Peak output apparent power	7500 VA, 10s
	Rated Current (@230V)	26.1 A
	Max. output current	22.7 A
	Max. switch time	22.7 A
	Output THDi (@ Linear load)	< 3%
Effi-	MPPT efficiency	99.90%
	Euro efficiency / Max. efficiency	97% / 97.6%
	Max. battery to load efficiency
Safety protection	DC-side disconnection device	●
	PV string- / Battery input reverse polarity protection	● / ●
	All-pole sensitive residual current monitoring unit	●
	Anti-islanding protection	●
	Ground fault protection	●
	Ground fault protection	● / ●
	AC over voltage protection	●
	Protection class (as per IEC 62109-1) / overvoltage category (as per IEC 62109-1)	I / AC: III; DC: II
General data	Power factor at rated power / adjustable displacement	≥0.99 /0.8 leading to 0.8 lagging
	Dimensions (W / H / D)	494/420 / 195 mm
	Device weight	21.5 kg
	Operating temperature range	-25 °C … +60 °C
	Noise emissions (typical)	30 dB(A)
	Standby consumption	< 10 W
	Cooling concept	Natural convection
	Degree of protection (as per IEC 60529)	IP66
	Climatic category (according to IEC 60721-3-4)	4K4H
	Max. permissible value for relative humidity (non-condensing)	100%
	Max. operating altitude	4000m (>3000m power derating)
Features	User interface	LED & App
	Communication with BMS	RS485 / CAN
	Communication with meter	RS485
	Communication with portal	WIFI stick
	Other communication	DRM
	Integrated power control / Zero export control	● / ●

● Standard features / ○ optional features / – not available
*1 For VDE-AR-N4105,Smax=Sn=4600VA,Pn=4600W
*2 For AS/NZS4777.2,Iac max=21.7 Version: March 2022
